PartNo.:10411
Description: 10411-METRIC FEMALE 24° CONE SEAT L.T.
Convertible code:
Material:Carbon Steel 45#
Surface Treatment: Zinc,Cr3+Plating,Clear White
Corrossion Resistent Hour: 120h or longer
Degree:Straight
| PARTNO. | THREADE | HOSEBORE | TUBEO.D. | DIMENSIONS | |||
| DN | DASH | A | C | S1 | |||
| 10411-12-04 | M12x1.5 | 6 | 4 | 6 | 21.5 | 10 | 12 |
| 10411-14-04 | M14x1.5 | 6 | 4 | 8 | 21.5 | 10 | 14 |
| 10411-14-05 | M14x1.5 | 8 | 5 | 8 | 22 | 10 | 14 |
| 10411-16-04 | M16x1.5 | 6 | 4 | 10 | 23 | 11 | 17 |
| 10411-16-05 | M16x1.5 | 8 | 5 | 10 | 23 | 11 | 17 |
| 10411-16-06 | M16x1.5 | 10 | 6 | 10 | 23 | 11 | 17 |
| 10411-18-05 | M18x1.5 | 8 | 5 | 12 | 23.5 | 11 | 19 |
| 10411-18-06 | M18x1.5 | 10 | 6 | 12 | 23.5 | 11 | 19 |
| 10411-22-06 | M22x1.5 | 10 | 6 | 15 | 24.5 | 12 | 24 |
| 10411-22-08 | M22x1.5 | 12 | 8 | 15 | 26 | 12 | 24 |
| 10411-26-08 | M26x1.5 | 12 | 8 | 18 | 26.5 | 12 | 27 |
| 10411-26-10 | M26x1.5 | 16 | 10 | 18 | 27 | 12 | 27 |
| 10411-27-10 | M27x1.5 | 16 | 10 | 18 | 29.5 | 14 | 30 |
| 10411-30-10 | M30x2 | 16 | 10 | 22 | 29.5 | 14 | 32 |
| 10411-30-12 | M30x2 | 20 | 12 | 22 | 30 | 14 | 32 |
| 10411-36-16 | M36x2 | 25 | 16 | 28 | 31.5 | 14 | 38 |
| 10411-45-20 | M45x2 | 32 | 20 | 35 | 38 | 16 | 46 |
| 10411-52-24 | M52x2 | 40 | 24 | 42 | 40 | 16 | 55 |
10411-Metric Female 24°Cone Seat L.T. Introduction
The 10411-Metric Female 24° Cone Seat L.T. is a high-performance fitting specifically designed for metric fluid systems operating under low-temperature (L.T.) conditions. This precision-engineered component offers superior sealing capabilities and durability, making it a reliable choice for a wide range of industrial applications.
The key feature of the 10411-Metric Female 24° Cone Seat L.T. is its 24° cone seat design. This unique angle ensures a secure and tight seal with its corresponding male component, effectively preventing leaks and maintaining fluid integrity even under extreme pressure and low-temperature conditions.
Manufactured from high-quality materials, the fitting exhibits excellent resistance to cold-related degradation, ensuring its longevity and performance even in freezing environments. Its robust construction also ensures that it can withstand the rigors of industrial use, making it suitable for use in harsh and demanding applications.
The 10411-Metric Female 24° Cone Seat L.T. is designed for ease of installation and disassembly, with smooth surfaces and precision threads that facilitate quick and efficient connections. This helps to minimize downtime and enhance operational efficiency, making it an ideal choice for systems that require frequent maintenance or modification.
In conclusion, the 10411-Metric Female 24° Cone Seat L.T. is a reliable and efficient fitting that offers superior sealing capabilities and durability for metric fluid systems operating under low-temperature conditions. Its precision engineering and high-quality materials ensure its long-term performance and make it a valuable addition to any industrial fluid system that demands secure and leak-free connections.
